AEMC 5070 Megohmmeter Graphical 5KV Insulation Tester
AEMC 5070 5000V Graphical Megohmmeter with revolutionary display method graphs insulation resistance & test voltage over time, giving operator an intuitive & better understanding of insulation's breakdown properties over duration of test
- 500V, 1000V, 2500V & 5000V preset test voltages
- Expanded insulation resistance measurement range from 1k Ohm to 10,000G Ohms (10T Ohms)
- Test voltage also manually adjustable or programmable from 50 to 5000V
- Automatic step voltage with programmable step & dwell; graphical display shows voltage stepping up concurrently with insulation resistance over time
- Automatic test run, calculation & display of DAR (dielectric absorption ratio), PI (polarization index) & DD (dielectric discharge) values
- Direct readout of test piece Capacitance and Leakage Current
- Smooth & Alarm functions
- Programmable test run time and PI time
- Temperature Compensation of readings
- AC or DC powered with rechargeable batteries
- Simultaneously displays Resistance, Test Voltage & Run Time digitally above graph: relates to real time values during test & cursor location after test
- Large bright-blue electroluminescent graphical backlit display, with high 320 x 340 pixel resolution
| Product Includes | 5070 megohmmeter, DataView Lite Software, soft accessory bag, red, blue & black test leads with 5kV rated "hippo" clips, guard terminal jumper, eight NiMH rechargeable batteries & 120V power cord |
| Specifications |
User Selectable Test Voltage: 50 to 1000V: 10V increments 1000 to 5000V: 100V increments Test Voltage / Insulation Range 500V: 20k Ohm to 2000G Ohm (2TW), 1000V: 40k Ohm to 4000G Ohm (4TW), 2500V: 100k Ohm to 10,000G Ohm (10T Ohm). 5000V: 200k Ohm to 10,000G Ohm (10T Ohm) Automatic Step Voltage Test: Programmable step voltage & duration (dwell) in five steps. Three profiles can be stored |
| Shipping Weight | 20.0000 |
| Manufacturer | AEMC |
| MPN | 5070 |
| Manufacturer Warranty | 1 year |
| Mitchell Catalog Number | 7Z213030,8Z213030, WB213030 |
