| Specifications |
| Bandwidth |
60 MHz |
| Number of channels |
60 MHz: 2 channels |
| Real-time sample rate |
625 MS/s |
| Inputs |
2 scope plus DMM input |
| Independently floating isolated inputs |
Up to 1000 V CAT III/600 V CAT IV between inputs, references and ground |
| Timebase range |
10 ns - 2 min/div |
| Input sensitivity |
2 mV-100 V/div |
| Trigger types |
Connect-and-View™, Free Run, Single Shot, Edge, Delay, Dual Slope, Video, Video Line, Selectable pulse width, N-Cycle |
| Trigger source |
Any scope input channel, or external via DMM input |
| Glitch capture |
8 ns |
| Scope measurements |
Cursor: 7 |
| Automatic: 30 |
| Maximum record length |
ScopeRecord mode: 30,000 pts |
| Scope mode: 10,000 pts per input |
| Persistence |
Digital persistence giving analog oscilloscope-like waveform decay |
| Waveform compare |
Waveform reference with automatic Pass/Fail testing |
| DMM Specification |
| Meter inputs (also used as External Trigger Input for the Oscilloscope Mode) |
4 mm banana inputs, fully isolated from scope inputs and from scope ground |
| Maximum resolution |
5000 counts |
| Measurements |
VDC, VAC rms, VAC + DC rms, Resistance, Continuity, Diode Test, Current (through clamp or shunt), Temperature °C or °F (using optional converter) |
| Memory |
2 Channel |
| Screen + Setup: 30 |
| Recording: 10 |
| Display |
153 mm full color LCD with fast update rate |
| Environmental Specifications |
| Operating temperature |
0°C to 40°C Including Batteries |
| 0°C to 50°C Excluding Batteries |
| Storage temperature |
-20°C to +60°C |
| Operating altitude |
Up to 2,000 m (6666 ft) for CAT IV 600 V, CAT III 1000 V |
| Up to 3,000 m (10,000 ft) for CAT III 600 V, CAT II 1000 V |
| Safety Specifications |
| Electrical safety |
1,000 V CAT III/600 V CAT IV (EN61010-1) |
| Mechanical and General Specifications |
| Size |
270 x 190 x 70 mm |
| Weight |
2.2 kg |
| Warranty |
3-years on main instrument, 1-year on accessories |
| Li-Ion battery |
BP290 2400 mAh Li-ion battery up to 4 hours included standard |
| Included Accessories |
| |
VPS410 Voltage Probe Sets (one red, one blue) |
| TL175 TwistGuard™ safety designed Test Lead Set (red and black) |
| BC190 Battery Charger/mains Adapter |
| BP290 2400 mAh Li-ion Battery |
| Handstrap (affixed to instrument) |
| Hangstrap |
| Multi-Language User Manuals on CD-Rom |
| FlukeView ScopeMeter® demo package (restricted functionality) |
| USB Interface Cable |
| Warranty |
Three years on main instrument, one year on accessories |
