| Technical Specifications | ||
| Display | VFD multi segment display, dual readings | |
| Resolution | 5.5 digits | |
| V DC | Range | 200 mV to 1000 V |
| Max. resolution | 1 uV | |
| Accuracy | 0.015 + 0.003 | |
| V AC | Range | 200 mV to 750 V |
| Max. resolution | 1 uV | |
| Accuracy | 0.2 + 0.05 | |
| Frequency | 20 Hz to 100 KHz | |
| Resistance | 2 x 4 Wire | Yes |
| Range | 200 Ω to 100 MΩ | |
| Max. resolution | 1 mΩ | |
| Accuracy | 0.02 + 0.003 | |
| A DC | Range | 200 µA to 10 A |
| Max. resolution | 1 nA | |
| Accuracy | 0.02 + 0.005 | |
| A AC | Range | 20 mA to 10 A |
| Max. resolution | 100 uA | |
| Accuracy | 0.3 + 0.06 | |
| Frequency | 20 Hz to 2 kHz | |
| Frequency | Range | 20 Hz to 1 MHz |
| Max. resolution | 0.1 mHz | |
| Accuracy | 0.01% | |
| Math functions | dB/dBm | Yes |
| Advanced functions | Limit compare test, with pass and fail indicators | |
| Interfaces | RS-232, USB with optional adapter | |
| Programming languages/modes | Simplified ASCII, Fluke 45 remote command emulation | |
| General Specifications | ||
| Weight | 2.1 kg (4.6 lbs) | |
| Size (H x W x D) | 88 x 217 x 297 mm (3.46 x 8.56 x 11.7 in) | |
| Safety | Designed to comply with EN 61010-1:2001, ANSI/ISA 61010-1 (S82.02.01):2004, UL 61010-1:2004, AN/CSA C22.2 No. 61010.1:2004 | |
| Calibration documentation | Statement of calibration practices included; calibration report optional | |
| Warranty | Three years | |
