| TEST RANGE | |
| 54/74 series TTL | |
| CMOS 40/45 | |
| DRIVE | |
| TEST VOLTAGE | |
| 2.5/3.0/3.3/5V | |
| TEST TIME | |
| Average Search Time: 0.6 Sec | |
| DISPLAY | |
| 16 Characters in 1 line LCD | |
| POWER SOURCE | |
| AC 100V~240V+10%, 50/60Hz | |
| DIMENSIONS & WEIGHT | |
| 335(W) x 105(H) x 300(D) mm Approx. 1.5kg |
|
Features
-
Loop Test
-
Auto-Search
-
Self-Diagnosis
-
Over-Load Protection
-
Measures 1800 Kinds of Device
-
54/74 Series TTL
-
4000 and 4500 Series CMOS
-
Test Socket: 28 Pin
