• Dimension(W×D×H) : 400×400×800mm
• Power source : AC 220V 50/60Hz 2.5A
• Weight : 26kg
• Distinguished Features
Evaporating flask : 5000ml
Receiving flask : 3000ml
Digital speed control
Digital R.P.M Display
Speed control range : 20~280 R.P.M
Vertical type condenser
Digital interior temperature measure and display
 (It catches the temperature changes caused by the interior pressure drops)
Motorized UP- DOWN control switch
Easy to utilize standard distillation solution

Included Water bath HS-3001 (PTFE coating)

• Heater: 1500W
• Bath Material: SUS304
• Weight: 3.5kg
• Bath Dimension(φ * H)mm: 300*150 (Capacity : 6ℓ)
• Required Power Source : AC 220V 50/60Hz 3.5A
• Distinguished Features
If the amount of water goes down under the certain threshold in the heating bath, the system automatically turns off its power for the safety purpose
Temp.Control range: Amb.~180℃
Temp.Setting/Display : Digital control(controlled by the main controller)
※Double jacketed bath body (Safe to touch)

Included vacuum controller
Vacuum range : 0~760mmHg
