An affordable, easily deployable, and portable air monitor designed for measuring trace level for ambient air pollution. The unique sampling design allows for real-time data and filter gravimetric analysis utilizing the FRM 47mm Cassette located directly behind the optical sensor. EPAM-5000 offers a weather tight carrying case, temperature compensated electronics, easy to clean optical sensor and a standard 24 hour battery or continuous sampling with solar power panel accessory. Network up to 8 Haz-Dust™ Model EPAM-5000 systems and add up to 5 miles wireless data transmission to central PC or MAC computer.

Applications

• US EPA air monitoring studies
• Compliments fixed monitoring sites with real time graphical reports
• Perimeter monitoring
• Emergency Response

• Real-Time display and data storage
• 47mm FRM cassette
• High correlation to EPA FRM
• E-Z to clean optical sensor & 4.0Lpm
• user adjustable sampling pump
• Network 8 systems together

Weatherproof Enclosure

Inline 47mm FRM Cassette

Sensing range: .001-20.0 and/or .01-200.0 mg/m³

PM size range: .1-100 µm

Sampling flow rate: 4.0 LPM

Alarm output: 90 db at 3 ft

Analog Output: 0-2 Vdc

Digital output: RS-232--Record Time: 1 s. to 15 mon.

Display: Real-Time mg/m3

Operating temp: -10°C -50°C Battery: Rechargeable 24hr

Weight: 12 lbs

Dimensions: 14 x 6 x 10 in.
