Basic specifications (Accuracy guaranteed for 1 year)Note: Cannot use with Model CT 9279
| Rated primary current | AC 1000 A continued (Maximum 1500 A for 5 minutes or shorter) |
|---|---|
| Rated secondary current | AC 100 A (10 : 1 CT ratio) |
| Amplitude accuracy | ±1.5% rdg. |
| Phase accuracy | ±1.0 ° or less |
| Frequency characteristic | Amplitude: 20 Hz to 5 kHz: ±2.0 % rdg. (deviation from accuracy) Phase: 20 Hz to 5 kHz: ±1.0 ° or less (deviation from accuracy) |
| Max. rated voltage to earth | 600 V AC rms (insulated wire) |
| Core jaw dia. | φ 55 mm (2.17 in) or 80 mm (3.15 in) × 20 mm (0.79 in) busbar |
| Dimensions and mass | 99.5 mm (3.92 in) W × 188 mm (7.40 in) H × 42 mm (1.65 in) D, 580 g (20.5 oz), cord length 3 m (9.84 ft) |
| Accessories | Instruction manual ×1, Mark band ×6 |
