Basic specifications (Accuracy guaranteed for 1 year, Post-adjustment accuracy guaranteed for 1 year)
| AC current | 30.00 m/ 300.0 m/ 6.000/ 60.00/ 600.0/ 1000 A, 6 ranges, 45 Hz to 400 Hz, True RMS Basic accuracy: ±1.5% rdg. ±5dgt. (50/60 Hz, filter ON) |
|---|---|
| AC voltage | N/A |
| Frequency | N/A |
| Crest factor | 2.8 or less (1.68 or less at 1000 A range) |
| Filter function | Cut off frequency 180 Hz at filter ON (-3 dB) |
| Output function | N/A |
| Other functions | Flip-open mechanism (but still retaining proper orientation of display), Backlight, Maximum value display, Data hold, Auto power off |
| Display | Digital LCD, max. 6000 dgt., 91 segments Display refresh rate: 1.1 sec or less |
| Power supply | Coin type lithium battery (CR2032) ×1, Continuous use 18 hours |
| Core jaw dia. | φ 24 mm (0.94 in) |
| Dimensions and mass | 50 mm (1.97 in) W × 130 mm (5.12 in) H × 26 mm (1.02 in) D, 135 g (4.8 oz) |
| Accessories | Carrying Case 9757 ×1, Strap ×1, Instruction manual ×1, Coin type lithium battery (CR2032, for trial purposes only) ×1 |
