Basic specifications (Accuracy guaranteed for 1 year, Post-adjustment accuracy guaranteed for 1 year)
| DC Voltage range | 6/30/60/300/600V (20 kΩ/V) Accuracy: ±2.5 % f.s. |
|---|---|
| AC Voltage range | 6/30/150/300/600 V (10 kΩ/V) Accuracy: ±2.5 % f.s. , Average rectifier effective value |
| Resistance range | 0 to 10 kΩ (center scale 100 Ω), R × 1, R × 10, R × 100 Accuracy: ±3 % of scale length |
| Power supply | For resistance measurement range, R6P (AA) × 2 batteries |
| Safety considerations | Circuit: Fuse-protected, internal circuit protection using the 10Ω resistance Meter: Diode-protected |
| Dimensions and mass | 94 mm (3.70 in) W × 134 mm (5.28 in) H × 56 mm (2.20 in) D, 350 g (12.3 oz) |
| Accessories | Test Lead 9060 ×1, Spare fuse ×1, R6P (AA) manganese battery ×2, Instruction manual ×1, Carrying case ×1 |
