Features and Benefits
• Conforms to FTM 791-3452 specifications
• Digital-indicating controls and built-in temperature recorder
Specifications
Conforms to the specifications of: FTM 791-3452
Journal Drive Motor: 5hp variable speed, with digital 0-3500rpm control. Fan cooled with thermal overload protection.
Lubricant Flow: 3.8L/min. gear pump recirculating 1.9-23L/min. of test lubricant to support bearing and test bearing. Digital oil pressure circulation.
Temperature Control: Sump temperature (0-500°F) with digital indication and recording of temperature at bearing housing, sump and in-line.
Bearing Load: Hydraulic loading device maintaining 1520 kPa (220 psig) on the loading bearing.
Electrical Requirements
200-240V 50/60Hz, 3-Phase, 20A
380V 50/60Hz, 3-Phase, 12A
440V 50/60Hz, 3-Phase, 10A
Dimensions lxwxh,in.(cm)
48x36x54 (122x91x137)
Net Weight: 1300 lbs (589.7kg)
Shipping Information
Shipping Weight: 1582 lbs (717.6kg)
Dimensions: 101.7 Cu. ft.
