| Test Method A quantity of 65g of a lubricant is placed in an evaporative crucible and heated to 250°C for 60 minutes. The evaporation loss tendencies of the lubricant are determined by passing a constant air stream over the heated sample by means of a vacuum pump. Features and Benefits • Conforms to ASTM D5800, DIN 51581 specifications • Non-woods Metal or Woods Metal heating bath |
Specifications
Conforms to the specifications of: ASTM D5800; DIN 51581
Capacity: 1 sample
Temperature Range: 150 to 350°C
Temperature Accuracy: ±0.1°C
Electrical Requirements
115V 60Hz, 12.0A
230V 50Hz, 5.8A
Dimensions lxwxh,in.(cm)
Non-Woods Metal Noack Tester with Stand and Glassware Set: 23.25x14.5x26.75 (59x36.8x68)
Net Weight: 59 lbs (26.7kg)
Woods Metal Noack Tester: 18x14.5x14.5 (45.7x36.8x36.8)
Glassware Set and Vacuum Regulator: 23.25x14.5x26.75 (59x36.8x68)
Net Weight: 84.25 lbs (38.2kg)
Required Accessories
Glassware Set, consisting of (2) bottles with ground stoppers, glass tubes, and tubing set
Vacuum Pump
Evaporation Crucible
Crucible Wrench and Clamp
Reamer, 2mm diameter
5 Test Balls, 3.5mm diameter
Protection Gloves
300g Woods Metal and Brush
Stand with Inclined Manometer (range: 0-30mm H2O) and Bleed Valve for Manual Regulation of Air Stream
Shipping Information
Shipping Weight:
Non-Woods Metal Unit: 124 lbs (56kg)
Woods Metal Unit: 62.5 lbs (28.4kg)
Dimensions:
Non-Woods Metal Unit: 5.0 Cu. ft.
Woods Metal Unit: 7.3 Cu. ft.
