• Voltage, Current, Power Factor and Frequency measurements
• Power analysis (Active, Apparent and Reactive power)
• Energy analysis (Active, Apparent and Reactive power)
• Active power accuracy: ±0.3%rdg±0.2%f.s.
• Automatic wiring check function to prevent incorrect connections
• Large memory capability (2GB) using built-in SD card interface
• Real time & remote measurements using Android application
• synchronous measurements between two units of KEW 6305
• Wide selection of clamp sensors allow measurements from 0.1A to 3000A
• The instrument automatically recognizes what kind of clamp sensor is connected to it
• Windows software for data analysis and setting via USB port or Bluetooth
• Power analysis (Active, Apparent and Reactive power)
• Energy analysis (Active, Apparent and Reactive power)
• Active power accuracy: ±0.3%rdg±0.2%f.s.
• Automatic wiring check function to prevent incorrect connections
• Large memory capability (2GB) using built-in SD card interface
• Real time & remote measurements using Android application
• synchronous measurements between two units of KEW 6305
• Wide selection of clamp sensors allow measurements from 0.1A to 3000A
• The instrument automatically recognizes what kind of clamp sensor is connected to it
• Windows software for data analysis and setting via USB port or Bluetooth
 |
Free Android software "KEW smart 6305" is available on "Google Play Store" •Supporting Android ver. 3.0 - 6.0 Please search "KEW Smart" in Google Play Store. |
| Wiring connections | 1P2W, 1P3W, 3P3W, 3P3W3A, 3P4W |
|---|---|
| Measurements | Voltage, Current, Frequency, Active power |
| Parameters | Apparent power, Reactive power, Active energy, Apparent energy, Reactive energy, Power factor (cos θ), Neutral current |
| Voltage range[RMS] | 150.0 / 300.0 / 600.0V |
| Voltage accuracy | ±0.2%rdg±0.2%f.s. (sine wave, 45 - 65Hz) |
| Current range[RMS] | 8128 ( 50A type ) : 1.000 / 5.000 / 10.00 / 25.00 / 50.00A / auto 8127 ( 100A type ) : 2.000 / 10.00 / 20.00 / 50.00 / 100.0A / auto 8126 ( 200A type ) : 4.000 / 20.00 / 40.00 / 100.0 / 200.0A / auto 8125 ( 500A type ) : 10.00 / 50.00 / 100.0 / 250.0 / 500.0A / auto 8124 ( 1000A type ) : 20.00 / 100.0 / 200.0 / 500.0 / 1000A / auto 8130 ( 1000A type ) : 20.00 / 100.0 / 200.0 / 500.0 / 1000A / auto 8129 ( 3000A type ) : 300.0 / 1000 / 3000A |
| Current accuracy | ±0.2%rdg±0.2%f.s. + Accuracy of Clamp sensor (sine wave, 45 - 65Hz) (*) +1%f.s. at the lowest range |
| Display range | 5 - 130% of each range(Voltage) 1 - 130% of each range(Current) |
| Crest factor | Voltage: up to 2.5, Current: up to 3.0 (with 90% fs or less) |
| Active power accuracy | ±0.3%rdg±0.2%f.s. + Accuracy of Clamp sensor (*) +1%f.s. when the lowest current ranges is selected. |
| Effect of power factor | Active power: ±1.0%rdg cos θ=±0.5 (PF=1) |
| Frequency meter range | 40.0 - 70.0Hz |
| Frequency meter accuracy | ±3dgt |
| Accuracy precondition | PF=1, Sine wave, 45 - 65Hz, 23ºC±5ºC |
| Display update period | 1 second |
| Applicable standards | IEC 61010-1 CAT III 600V |
| Operating temperature & humidity range | 0 - +50ºC, less than 85%RH (without condensation) |
| Storage temperature & humidity range | -20 - +60ºC, less than 85%RH (without condensation) |
| Power supply (AC Line) | AC100 - 240V±10% (50/60Hz) |
| Power supply (DC battery) | LR6 or Ni-MH (HR-15-51) ×6 (Battery charger not included), Battery life approx. 15h (LR6) |
| Power consumption | 10VA (max.) |
| communication interface | USB, Bluetooth |
| PC card interface | SD card (2GB) |
| Dimensions | 175(L)×120(W)×65(D) mm |
| Weight | Approx. 800g (including batteries) |
| Included Accessories | 7141B (Voltage test lead set: 4pcs) 7148 (USB cable) 7170 (Power cord) 9125 (Carrying case) 8326-02 (SD card 2GB) KEW WINDOWS (PC Software) Battery (LR6)×6 Quick manual |
| Optional Accessories | 8124, 8125, 8126, 8127, 8128 (Clamp sensor) 8129/8130 (Flexible clamp sensor) 8312 (Power supply adaptor) 9132 (Magnetic carrying case) |
Set Model
- KEW 6305-01
- KEW 6305 × 1
- MODEL 8125 × 3
- 7141B (Voltage test lead set: 4pcs) × 1
- 7148 (USB cable) × 1
- 7170 (Power cord) × 1
- 8326-02 (SD card [2GB]) × 1
- 9125 (Carrying case) × 1
- PC Software × 1
- Battery × 6
- Quick manual × 1
- KEW 6305-03
- KEW 6305 × 1
- KEW 8130 × 3
- 7141B (Voltage test lead set: 4pcs) × 1
- 7148 (USB cable) × 1
- 7170 (Power cord) × 1
- 8326-02 (SD card [2GB]) × 1
- 9135 (Carrying case) × 1
- PC Software × 1
- Battery × 6
- Quick manual × 1
