l Precise non-contact measurements
l Built-in laser pointer
l User selectable ºC or ºF
l MAX/MIN temperature displays
l Trigger lock
l Automatic Data Hold & Auto power off
l Automatic selection range and Display Resolution 0.1ºC(0.1ºF)
l The meter at 8 inches away measure 1 inch target
l Backlit LCD display
Wide range application:
Food preparation, Safety and Fire inspectors, Plastic molding, Asphalt, Marine and screen printing, measure ink and dryer temperature, Diesel and Fleet maintenance.
Field of View
meter’s field of view is 13:1, meaning that if the meter is 8 inches from the target, the diameter of the object under test must be at least 1 inch. Other distances are shown below in the field of view diagram. Refer to the chart printed on the meter for more information.
SPECIFICATIONS
General specifications
|
MEAS. RANGES
|
-50℃ to 850℃/-58℉to 1562℉
|
|
RESPONSE TIME
|
Less than 1 second
|
|
OVER RANGE INDICATION
|
LCD will show “------”
|
|
POLARITY
|
Automatic (no indication for positive polarity); Minus (-) sign for negative polarity.
|
|
EMISSIVITY
|
0.95 fixed value
|
|
FIELD OF VIEW
|
D/S = Approx.13:1 ratio (D = distance, S = spot)
(Has 90% encircled energy at the focal point)
|
|
DIODE LASER
|
Output <1mW, Wavelength 630~670nm,class 2 (II) Laser product
|
|
SPECTRAL RESPONSE
|
8~14um
|
|
POWER OFF
|
Automatic shut off after 8 seconds, approx.
|
|
OPERATING TEMP.
|
0℃ to 50℃ (32℉to 122℉)
|
|
STORAGE TEMP.
|
-20oC to 60oC(-4oF to 140oF)
|
|
RELATIVE HUMIDITY
|
10%~90%RH operating, <80%RH storage
|
|
POWER SUPPLY
|
9V battery, NEDA 1604A or IEC 6LR61, or equivalent
|
|
WEIGHT
|
130g.
|
|
SIZE
|
145*98*42 mm
|
