| Physical | |
|---|---|
| Dimensions (hxwxd) | 160 x 166 x 73 mm |
| Weight | 1.0 kg |
| Protection Class | IP65 |
| Enclosure Material | ABS |
| Cable Entry | 1x M20, 4x M16, 1x M12 |
| Cable Core Size | Max Conductor Size 2.5 mm² |
| Electrical | |
| Power Supply | 100 to 240 VAC 50/60 Hz or 9-30 VDC |
| Power Rating | 15 W |
| Environmental Data | |
| Operating/Storage Temperature | -20 to 60ºC, 0-95% Relative Humidity, Non-Condensing |
| Location | Indoor/Outdoor |
| User Interface | |
| Display | Graphical LCD, providing 4 1/2 digits with 2 message lines |
| Back Light | On/Off/On after Keypress with user adjustable contract |
| Membrane Keypad | 6 Key, pillow embossed |
| Units of Measurement | mg/l, g/l, ppm, NTU, FTU, %SS, User Defined |
