| Physical | |
|---|---|
| Dimensions (hxwxd) | 800 x 450 x 300 mm |
| Weight | 25 kg |
| Protection Class | IP55 |
| Electrical | |
| Power Supply | 12 VDC or 115/230 VAC |
| Power Rating | 4W on standby , 10W during analysis |
| Environmental Data | |
| Operating Temperature | 10 to 30ºC |
| Location | Indoor or in Protective Kiosk |
| User Interface | |
| Display | 3 Digit, 7 Segment LED Display of 0-100% |
| Setup | Potentiometer and Push Buttons on main PCBA |
| Units of Measurement | %age Depth |
| Output Signals | |
| Analogue Output | 4-20 mA, max load 500 ohm |
| Relays | 1, this alarms at 0 and 100% and is not adjustable |
| Contacts | Contact Closure, 0.55 A @ 100VDC |
| Local Annuication | 6 LED's on main PCBA |
