| Physical | |
|---|---|
| Dimensions (hxwxd) | 280 x 230 x 130 mm |
| Weight | 1.7 kg including sensor and 10 metres of cable |
| Protection Class | Electronics: IP54 Sensor: IP68 |
| Enclosure Material | Dark Blue Nylon |
| Cable Length | 10 metres standard, 15 metres maximum |
| Electrical | |
| Power Supply | 9V Battery (PP3) |
| Battery Life | 6 months typical use |
| Environmental Data | |
| Operating Temperature | 0 to 40ºC, limited by the risk of ice formation interfering with the measurement |
| Storage Temperature | -20 to 60ºC |
| Location | Indoor/Outdoor |
| User Interface | |
| Display | Front Panel LED - 'ON' in Sludge |
| Audible Output | Short Tone in Water Long Tone in Sludge |
