Benefits
- Routine SDI measurement can prevent membrane fouling and improve the efficiency of RO systems.
- Automated test process for simpler, easier and accurate SDI measurements.
- Compact, Lightweight and battery powered for easy portability.
- Performs SDI 5, 10 and 15 minute tests with both 100 ml and 500 ml sample size tests – provides useful data which is especially helpful on high SDI waters.
- Unattended operation. Start the test and return in 15 minutes for the results – saves you time.
- Real-time display of results including SDI, current flow rate and elapsed time. End of test display includes SDI
- 5, 10 & 15 with 100 ml and 500 ml results.
- More accurate than hand testing (ASTM D 4189-95) – consistent results provides better information.
- Uses standard 47 mm membrane filters – for lower consumable cost and worldwide availability.
Features
|
|
|
|
SDI (Silt Density Index) Testing for:
- Reverse Osmosis
- UltraFiltration
- MicroFiltration
Spare Parts and Optional Components:
|
Model No. |
Description |
|
SDI-045 |
Filters for Silt Density Index Testing, 0.45 Micron, 47 mm, Package of 100 |
|
K2305JJ |
Pre-filter 5M inline, Omnipure |
|
182-11001 |
Battery 6V 1.3 AH SLA type |
|
182-40005 |
Booster pump for 110Vac, used when source water is less than 35 PSI |
|
182-40025 |
Booster pump for 220Vac, used when source water is less than 35 PSI |
|
182-30059 |
Pre-Filter 50m Inline |
|
182-30050 |
Pre-Filter 50m Inline ¼” QC |
|
182-11005 |
Power Supply/Battery Charger (110 Vac-60Hz) |
