Specifications
Range:
Wind speed: 0-100 m/s (224 mph) survival, 0-50 m/s (110 mph) signal
Wind direction: 360˚ mechanical, 355˚ electrical (5˚ open)
Accuracy:
Wind speed: ±0.3 m/s (0.6 mph) or ±1%
Wind direction: ±3 degrees
Threshold:
Propeller: 1.0 m/s (2.2 mph)
Vane: 1.1 m/s (2.4 mph)
Signal Output:
4 to 20 mA full scale for WS and WD
Power Requirement:
8-30 VDC (40 mA max.)
Dimensions:
Overall height: 37 cm (14.6 in)
Overall length: 55 cm (21.7 in)
Propeller: 18 cm (7 in) diameter
Mounting: 34 mm (1.34 in) diameter (standard 1 inch pipe)
Weight: 1.0 kg (2.2 lbs), Shipping weight: 2.3 kg (5 lbs)
