Specifications
Range:
Wind speed: 0-100 m/s (224 mph)
Wind direction: 0-360 degrees
Resolution:
Wind speed: 0.1 unit (m/s, knots, mph, km/h)
Wind direction: 1 degree
Accuracy:
Wind speed: ±0.3 m/s (0.6 mph) or 1% of reading
Wind direction: ±2 degrees
Threshold:*
Propeller: 1.0 m/s (2.2 mph) Vane: 1.1 m/s (2.5 mph)
Available Outputs:
Voltage Output:
WS: 0-5 VDC for 0-100 m/s
WD: 0-5 VDC for 0-540˚
Serial RS-485:
RMY, NCAR, or NMEA protocols
Polled or continuous output
Power Requirement:
11-24 VDC, 20 mA
Dimensions:
Overall: 37 cm (14.6 in) H x 55 cm (21.6 in) L
Propeller: 18 cm (7.0 in) diameter
Mounting: 34 mm (1.34 in) diameter (standard 1 inch pipe)
Weight: 1.0 kg (2.2 lbs), Shipping weight: 2.3 kg (5 lbs)
Operating Temperature: -50 to 50˚ C
