Specifications
Threshold: 1 mm (.04 in)
Accuracy: ±1 mm (±.04 in)
Signal: 0 to 5.00 VDC = 0 to 50 mm precipitation
Chamber Drain Time: 30 seconds approx.
Power Requirement: Measuring Circuit: 8 to 30 VDC, Heater: 48 Watts @ 28 VAC, Operating Temperature: -20˚C to +50˚C (-4˚F to 122˚F)
Dimensions:
Height: 65 cm (25.6 in)
Diameter: 14 cm (5.5 in)
Catchment Dia: 133 mm (4.4 in)
Catchment Area: 100 cm2 (60.8 in2)
Mounting: U-bolts fit vertical pipe 25-50 mm (1-2 in) diameter.
Weight: 2.5 Kg (5.5 lb)
Shipping Weight: 4 Kg (9 lb)
