Specifications
Size: 18 cm dia. x 30 cm high, (39 cm high with mounting base)
Catchment Area: 200 cm2
Resolution: 0.1 mm per tip
Accuracy: 2% up to 25 mm/hr 3% up to 50 mm/hr
Output: Magnetic reed switch (N.O.), rating 24VAC/DC 500mA
Operating Temperature: -20˚C to +50˚C (heated)
Power: 18 Watts for heater only
Mounting: Clamp for 1″ (1.34″ dia.) iron pipe or 3 bolts on 160mm dia. circle
Other: Leveling adjustment, thermostatic control for heater, intake screen
